Fibonacci Expansion Options

Brief

This section describes how to change the options for a Fibonacci expansion.

Details

To change the options

1. Do one of the following:

• On the File menu, click Options.
• Right-click in the vertical or horizontal scale, and then click Options.
• Right-click in the chart and then click Options.
  * In the E*TRADE FX platform, the command is available on the System menu.
2. The Options dialog will appear.
3. Double-click Fibonacci Options, and then click Retracement.


4. Change the options:

• To show a Fibonacci in a background by default, click Show in background, and then set the option to Yes. Otherwise, set the option to No.
• To show a Fibonacci label by default, click Show label, and then set the option to Yes. Otherwise, set the option to No.
• To show levels values in the legend of level lines by default, click Show levels on lines, and then set the option to Yes. Otherwise, set the option to No.
• To change the default color of levels values in the legend, click Level label color, and then from the Color palette, choose the color.
• To change the default color of a wave line, click Wave line color, and then from the Color palette, choose the color.
• To change the default width of a wave line, click Wave line width, and then type the width.
• To change the default style of a wave line, click Wave line style, and then click the arrow to select the style.
• To show a wave line by default, click Show wave line, and then set the option to Yes. Otherwise, set the option to No.
• To show prices in the legend of levels lines by default, click Show prices on lines, and then set the option to Yes. Otherwise, set the option to No.
• To change the default color of prices in the legend, click Price label color and then, from the Color palette, choose the color.
• To extend level lines to the left by default, click Extend Fibonacci lines start, and then set the option to Yes. Otherwise, set the option to No.
• To extend levels lines to the right by default, click Extend Fibonacci lines end, and then set the option to Yes. Otherwise, set the option to No.
5. Click OK.
